Product information
| Unit | Value | |
|---|---|---|
| Radiation geometry | - | Panoramic |
| Output voltage range | kV | 30 to 300 |
| Tube current range | mA | 0.5 to 1.0 |
| Tube current at full output | mA | 2.5 |
| Max. power at the anode | W | 750 |
| Constant power mode | - | Yes |
| Working cycle at 30°C | % | 100 |
| Steel penetration (**) | mm | 52 |
| Weight | Kg | 29.4 |
| Overall dimensions | mm | Ø 180 x 837 |
| Leakage dose at 1 m at full output | mS/h | < 5.0 |
| Optical focal spot (EN12543) | mm | Ø 0.5 x 5.5 |
| Max. useful angle | ° | 360 x (2x20) |
| Inherent filtration | mm | Equiv. 3.5 (Al) |
| Waterproof level | - | IP66 |
| Operating temperature | °C | -30 to +60 |
| Storage temperature | °C | -40 to +70 |
| Built-in carrousel featuring 5 outputs | - | No |
| Guard rings | - | No |
| (**) 700mm FFD, 10min, AA400, D=2 for CPD | - | - |
